Crowding Tub

CROWDING TUBS
NEED A SAFER WAY TO HANDLE YOUR CATTLE?
PROBLEM SOLVED.

8’ RADIUS [T8-SA90 | T8-SA180]
DIMENSIONS: 102” W X 86” H X 191” L | 102” W X 86” H X 188” L
WEIGHT: 1218 LBS.
MAX NUMBER OF ADULT CATTLE: 2-3
ALLEY LENGTH: 16’ (2X8’ ALLEYS)

10’ RADIUS [T10-SA90 | T10-SA180]
DIMENSIONS: 126” W X 86” H X 237” L | 126” W X 86” H X 235” L
WEIGHT:
SINGLE ALLEY 90° 1486 LBS.
SINGLE ALLEY 180° 1487 LBS.
MAX NUMBER OF ADULT CATTLE: 4-5
ALLEY LENGTH: 20’ (2X10’ ALLEYS)

Arrowquip's Cattle Crowding Tubs are a high capacity, high quality product designed to move your cattle quickly and safely into a chute, alley, or truck. The cattle tubs feature a tubular frame that is light-weight, yet durable enough to withstand the heavy-duty use of a crowding tub. The crowd gate lock-out and exit gate come standard on the Crowding Tub, and distractions are kept to a minimum with the sheeted sides. The tub features simple assembly, ensuring efficient set-up and tear down as necessary.

High-Quality Construction

All Crowding Tubs are built for heavy-duty work. Made with powder-coated American steel, the Crowding Tub is designed to withstand extreme weather conditions for long-term use. For added stability, the panels are bolted together and stabilized by joiner bars that connect to the center of the tub.

Crowd Gate Lock

The crowd gate automatically locks into position as you move the sweep through the tub, ensuring cattle cannot push back on the gate and cause injury to the handler. For quieter operation, the crowd gate lock features a rubber bushing to cushion the impact on the panels and reduce metal clanging. When not in use, the crowd gate lock can be disengaged to pull the sweep back in a smooth motion.

Fully Sheeted Sides

The fully sheeted sides on the Cattle Crowding Tubs safeguard cattle, as there are no foot traps or opportunity for them to injure themselves in the tub. 53" sheeting allows the handler to use point of balance handling techniques to assist with cattle movement.

Connect With Ease

Connecting your crowding tub to your alley or cattle corral panels is quick and easy. With four pin connections, seamlessly connect to any Arrowquip equipment.

Product Specifications

• Simple assembly
• Rectangular tubing limits cattle bruising and injury
• Primed and powder-coated steel ensures long-term durability of the equipment
• 14-gauge steel sheeting
• Sheet metal is caulked to reduce noise
• Crowd gate lock assists in sweeping so cattle are unable to push the gate back
• Center post features a rubber bumper to eliminate the gap between the post and back gate
