WEIGH PLATFORM KIT for 8´ Easy Flow Alley
WEIGH PLATFORM KIT for 8´ Easy Flow Alley
Couldn't load pickup availability
EASY FLOW ALLEY
WEIGH PLATFORM KIT
MODEL: [EWPF]
DIMENSIONS: 35” W X 6.2” H X 93” L
WEIGHT: 188 LBS.
Arrowquip's Easy Flow Alley Weigh Platform Kit can be added to an 8' Easy Flow Alley section of your complete cattle handling system to provide fast and accurate weigh-ins while keeping livestock flowing efficiently.
4 Steps to Efficient, Accurate Weigh-Ins:
1. 8’ Easy Flow Cattle Alley
2. Easy Flow Alley Weigh Platform Kit
3. Scale Mount Plates
4. Rolling Alley Gate
The Easy Flow Alley Weigh Platform Kit is made with heavy-duty 1/4" aluminum plate that provides excellent traction for hooves, and cradle shaped for seamless integration with an 8' Easy Flow Alley section. To install, add the Weigh Platform Kit (EWPF) and scale mount plates (SMP) to an assembled 8' Easy Flow Cattle Alley, ensuring there are rolling doors on each side of the alley section. This creates a designated scale section within your alley system, so you can effortlessly weigh your cattle before they enter the chute. Ensure weighing cattle is as easy as possible by using Tru-Test or Gallagher load bars.
Product Specifications
- Removable panels allow the operator to control what cattle see in the cattle alley
- For easy storage, removable panels are bolted onto the alley sides when not in use
- Cradle-shaped and fully adjustable to accommodate animals of any size
- Sides are sheeted to the ground, eliminating foot traps
- Durable clips allow the alley to connect with other Arrowquip products seamlessly
- Spring-load locking system on cam-slam latches for easy adjustment
- Top adjustment can be used to stop animals from rearing up
- Caulked flat sheeting on both sides to eliminate sheet metal rattling
- Nylon bushings over slam latch pins to reduce noise
- Panels bolt tightly together to eliminate pin rattling
- Lower bottom bar allows for safe entry and exit
- Both side panels drop down fully, allowing the handler to access the animal in case of emergency
- Safety latches on the side panels add security and control when adjusting, and ensure the sides will not drop down accidentally
